| Type | ORINIAL HARLEY MODEL | Capacity Ah/10HR | Dimensions(±2mm) | Weight (kg) |
Regular Charge Current (amp.) | Assembly Figure |
Terminal Type | CCA @-18℃ |
||
| L | W | H | ||||||||
| YGZ14H-BS | BA14SHD | 14 | 149 | 87 | 144 | 4.73 | 1.40 |  |
21 | 215 |
| YGZ14HL-BS | BA14LSHD | 14 | 149 | 87 | 144 | 4.73 | 1.40 |  |
21 | 215 |
| YGZ20H-BS | BA20SHDT | 19 | 176 | 87 | 153 | 6.02 | 1.90 | |
20 | 310 |
| YGZ20HL-BS | BA20LSHDT | 19 | 176 | 87 | 153 | 6.02 | 1.90 | |
20 | 310 |
| YGZ30HL-BS | BA30LSHDT | 30 | 166 | 130 | 175 | 9.24 | 3.00 | |
20 | 395 |
| YGZ30CHL-BS＃ | 30 | 166 | 130 | 175 | 9.24 | 3.00 | |
20 | 395 | |
