PRODUCT DESCRIPTION

5G wireless network Lithium ion batery

In view of the difficulty of expanding the capacity of municipal power, the power consumption of base station in 5G era will be considered according to the average power consumption of base station. At peak time, the base station will be charged by the common discharge of municipal power and lithium-iron batteries to ensure the power consumption of base station and the battery will be charged in the trough. Minimizing the quota of re-application for municipal electricity, speeding up the deployment and reducing the cost of power diversion.

At the same time, compared with traditional lead-acid batteries, lithium-iron batteries are lighter in weight, faster in deployment and less in construction, which solves the space and load limitation of the engine room and isolates them from the existing power supply schemes without affecting each other.

In addition, the 5G energy scheme uses 48V power supply, under the same conditions, the line loss is reduced by 60%, which further reduces the demand for electricity in the city

Introduction

Odp-dc1.5kw is the outdoor waterproof type -48V dc power supply designed by our company for telecom base station and other equipment. The input voltage range is 90-280vac, the output power is 1500W, and the lithium battery is equipped. This product has the following main features:

Introduction

1. The equipment is small in appearance, light in weight, and has strong heat dissipation and anti-interference ability, which facilitates the installation of various scenes; The waterproof shell protection grade meets the installation requirements of outdoor and harsh conditions.
2. Flexible mounting of 20Ah lithium battery to improve the stability of power supply system.
3. Wide input voltage range, high output efficiency, high voltage stability accuracy and low ripple noise.
4. The adapter has over-temperature protection, output overvoltage protection, current limiting protection and short circuit protection; The ability to protect shall meet relevant standards of the communications industry.
5. The input port of the power adapter can withstand the lightning strike of 20KA,8/20μS
6. Can be AC or DC (Optional)

PERFORMANCE CHARACTERISTICS

We provide one stop solutions to various field and professionaly tech supoprt since 2005 ,Fully automatic intelligent production equipment, combined with automation control technology and lithium battery
